Endress Hauser Easytemp PMP23 Compact Thermometer Customizable ODM Product
The Cerabar PMP23 is a compact and cost-effective pressure transmitter from Endress+Hauser designed for the measurement of absolute and gauge pressure in gases, vapors, and liquids. It is part of the Cerabar family and is widely used in general industrial processes as well as hygienic applications.
Measurement type: Absolute pressure or gauge (relative) pressure
Measuring cell: Piezoresistive sensor with fully welded 316L stainless steel flush-mounted diaphragm
Accuracy: Up to ±0.3% of span
Measuring ranges: From a few hundred mbar up to several tens of bar (depending on model)
Overload resistance: Designed to handle significant overpressure safely
Temperature range: Typical process temperature −10 … +100 °C, with short-term peaks higher (model dependent)
Output options: Standard 4–20 mA analog output; certain models also support IO-Link communication
Process connections: Available with multiple industrial and hygienic connections (e.g., threaded, clamp, flush)
Long-term stability: Excellent repeatability and drift resistance, reducing calibration needs
Compact design: Easy to integrate in space-limited installations
Reliable measurement of absolute and gauge pressure with a single platform
Cost-effective solution with robust performance for general process applications
Hygienic compatibility due to flush-mounted stainless steel diaphragm, suitable for food, beverage, and life sciences industries
Resistant to cleaning-in-place (CIP) and sterilization-in-place (SIP) procedures
High reproducibility and stability ensure long service life with minimal maintenance
Monitoring pressure in tanks, vessels, and pipelines
Process control in food & beverage, pharmaceuticals, water/wastewater, and general industry
Suitable for gases, vapors, and liquids where accurate and stable pressure measurement is required
